STAMPING PARTS

ENSURING EXCELLENCE WITH CUSTOMIZED ON-LINE CCD INSPECTION

Our customized on-line CCD inspection system ensures the highest standards of quality through various features. This includes cosmetic inspection and dimension measurement to ensure each part meets precise specifications. Our system automatically detects defects and immediately stops the production process, triggering an alarm for prompt review. Additionally, our system calculates the quantity of defective parts, enabling precise monitoring and control of the production.

OUR CAPABILITIES

DESIGN


  • 2D/3D CAD drawings/models
  • Strip layout optimisation
  • Design For Manufacturability (DFM)
  • FMEA / DFMEA
  • Reel-to-Reel and Reel-to-Bulk stamping
  • From prototype to mass-production tools
  • From 0.04mm to 3.5mm raw material thickness
  • Various copper alloys, steels and stainless steals
  • Pressing tonnage from 16 to 280 ton
  • Stamping speed top to 900 SPM
  • Pre-production services (e.g. plating, slitting)
  • Post-prodcution services (e.g. thermal treatment, de-burring, plating, passivation)
  • Reel-to-Reel and Reel-to-Bulk stamping
  • From prototype to mass-production tools
  • From 0.04mm to 3.5mm raw material thickness
  • Various copper alloys, steels and stainless steals
  • Pressing tonnage from 16 to 280 ton
  • Stamping speed top to 900 SPM
  • Pre-production services (e.g. plating, slitting)
  • Post-prodcution services (e.g. thermal treatment, de-burring, plating, passivation)

CAPACITIES FIXTURE DESIGN

3D Stamping/ Die casting





TOOL TYPES



  • Prototype / Single-stage
  • Multi-stage
  • Progressive tools/dies
  • In-tool riveting
  • In-tool tapping
  • High-speed (up to 900 SPM)
  • Wire forming



TOOL TYPES



  • Prototype / Single-stage
  • Multi-stage
  • Progressive tools/dies
  • In-tool riveting
  • In-tool tapping
  • High-speed (up to 900 SPM)
  • Wire forming
